We provide best quality of Vacuum Ejector Manufacturer & Supplier

Bhagwati PP Pump provides the finest quality Vacuum Ejector in India. Our products are highly esteemed in the market for their design and features. Vacuum Ejector is similar in hydraulic design to any conventional centrifugal pump. It differs in so far as it is always mounted in the vertical position. A restriction is provided above the impeller and the need for any form of liquid seal is obylated by allowing a small leakage to escape through an overflow connection in the upper pump body and return to the suction vessel.

Moreover, these pumps are widely appreciated for their trustworthiness and reliability. We have made accessible a wide range of Vacuum Ejectors for our well-regarded patrons. The high-class comprehensive design of these Vacuum ejectors increases their performance. Further, we also offer these products as per the client’s specific requirements.

Salient Features

  • Absolute reliability.
  • Robust and long working life.
  • Can be made from many corrosion resistance Material.
  • Easy handling even of large suction quantities.
  • Low capital, installation and maintenance costs.
  • Compact and light weight.
  • No moving part to wear or to go out of order.
  • Simple in operation.
  • No sealing and lubricating liquids are required as in mechanical system as per eg: Water ring vacuum pumps & high vacuum pumps.
vacuum ejector manufcturer
PP water jet vacuum ejector manufacturer

PP Vacuum Ejector with Vertical Glandless Pump

Material Of Construction

  • Cast iron
  • Cast Steel Carbon
  • Stainless Steel Lead
  • Monel Rubber Lined
  • Porcelain PVC
  • Teflon Polypropylene

Producing and maintaining high vacuum to moderate vacuum down to atmosphere in the following processes :-

  • Distillation
  • Evaporation
  • Refrigeration
  • Crystallization
  • Deodorization
  • Deaeration
  • Drying
  • Cooling (Evaporative)
  • Vacuum metallurgy
  • Filtration
  • Degassing
  • Debusting (in size reduction)
  • Heating, Pumping, Mixing and Stirring of Fluids, induced fluids can be Gases, Liquids, Slurries or liquids with granular solids in suspensions.
  • Exhausting and scrubbing of gases with liquids.

These Units Are Made in Following Types

Sr. No. Type Range of Suction Pressure
1 Water Ejector 32 mm. at shut off with 30°C water
2 One Stage Steam + Water Ejector 10 mm Hg. abs.
3 Two Stage Steam + One Stage of Water Ejector 2 mm Hg. abs.

Capacity Of Standard Units in M3/HR Free Air Displacement

Hp 1 2 3 5 7.5 10 15 20
M3/HR 6.5 25 50 80 160 240 330 440
CFM 4 15 30 50 95 140 200 260
Make Up Water LPM 4 5 6 8 16 20 30 40
